英国 HH TNE-212A 2x12" 有源全频音箱



查看大图
名称 :英国 HH TNE-212A 2x12" 有源全频音箱
型号 :英国 HH Tessen TNE-212A
关键字 :英国 HH TNE-212A 2x12" 英国 HH TNE-212A 2x12"有源音箱
系列 :数码音频 - PA 舞台音响类
描述

KEY SPECS:

Biamped Active Front of House Enclosure
2 way active crossover
500W RMS Class D amplifier with switch-mode power supply, comprehensive protection circuitry and clip free limiting
50W Class A/B amp for tweeter
60 – 20kHz
Balanced XLR input and link output
High order Active X-over with switchable EQ preshape
Trapezoid cabinet with internal bracing.
18mm rebated Plywood construction
Custom punch heavy gauge steel grille with acoustic foam front
12 industry standard Penn-Elcom M10 flying points

SPECIFICATION:

Cabinet Trapezoid cabinet with internal bracing. 18mm rebated Plywood construction
Cabinet fittings Custom recessed low profile HH rubber feet
Connections Balanced XLR/jack combi input & XLR link output
Controls Master Volume with EQ preshape switch. Power, Clip & Protect LED's
Crossover High order Active X-over with switchable EQ preshape
Finish Black spatter paint with routed logo
Frequency Response 60 - 20kHz
Grille Custom punch heavy gauge steel grille with acoustic foam front
Handles 4 way routed handles x 4
HF Driver HH GT-539F 1.4" exit compression driver with 50mm voice-coil and Titanium diaphragm
HF Power amplifier 50W RMS Class A/B
Length 0.52
LF Power amplifier 500W RMS Class D amplifier with switch-mode power supply, comprehensive protection circuitry and clip free limiting
Max SPL (calc) 128dB
Pole mount fitting None
Product Type Biamped Active Front of House Enclosure
Sensitivity (1W@1m) 101dB
Vol 0.29133
Weight 45
Width 0.498
Woofer 2 x HH HC-559K. Cast chassis 12" driver with Glass-fibre reinforced cone, Ribbon wire 76mm voice-coil and 97oz magnet
Mounting Points 12 industry standard Penn-Elcom M10 flying points
